BS 5837 Tree Protection Plan

3 October 2016

(updated 18th September 2018)

Section 3.

BS 5837:2012 Tree Protection Plan and Arboricultural Method Statement

To Accompany Planning Proposal:

'Ballabeg', Glen Vine, Isle of Man

Produced for: Hartford Homes Middle River Douglas Isle of Man IM2 1AL

Report produced by: Mr. Ben Brooker L4 DipArb (ABC), TechArborA, PTI Consulting Arborist Manx Roots Ltd. Tel: 07624259720 Em: [email protected]

Summary

The following Arboricultural Method Statement and Tree Protection Plan provide details on the specification and position of the required tree protection measures for this site. These protection measures most likely form all or part of a planning condition and therefore must be adhered to in full at all times.

If there is any deviation from the Arboricultural Method Statement and/or Tree Protection Plan, the project arboriculturist (tree specialist) must be informed immediately.

A 'Tree protection record of supervision' sheet has been provided below to help guide any monitoring process.

Annex 5. - Arboricultural Method Statement

1. Protective fencing and exclusion zones

1.1. Temporary protective fencing (as displayed below) will be installed to demarcate a Construction Exclusion Zone (CEZ) represented by orange hatch and a magenta line in the accompanying Tree Protection Plan (TP-26916v2). 1.2. The fencing will be installed for the purpose of excluding all construction activity and will consist of: heavy duty metal fencing panels fastened together and supported with manufacturer recommended ties, feet and stays. 1.3. The fencing will be fully installed prior to any demolition or construction activity and remain in place and fully effective until work is complete. 1.4. All weather notices will be attached to every second panel, clearly displaying words such as CONSTRUCTION EXCLUSION ZONE - NO ACCESS (see below). 1.5. The protective fencing will not be moved or disassembled without prior approval from the project arboriculturist. 1.6. Materials will not be stored within the CEZ. 1.7. Site personnel will not be permitted access within the CEZ. 1.8. All protective fencing will be inspected by the project arboriculturist prior work commencing and the inspection documented in the record of supervision. 1.9. The project arboriculturist will be informed by the site manager if the fencing is moved or if its specification is different from that described above.

Figure 1 shows metal (Heras style) fencing panels.

Notes:

Tree protection record of supervision
Name	Position	Mobile	Email
	Site Manager
	Architect
	Tree Officer
	Planning Officer
	Project Arboriculturist
	Other:
	Other:

Date (dd/mm/yy)	Operation	Completed Y/N Date	Comments	Project arboriculturist (signature)
	• Pre-development site meeting held. All tree protection measures discussed and agreed with site manager.
	• Tree pruning and removal carried out as per the Arb. Impact Assessment.
	• Protective fencing installed as per Tree Protection Plan and Arb. Method Statement.
	• Removal of asphalt road within CEZ overseen. • Protective fencing reinstated and fully effective.
	• Protective fencing dismantled.
	• Final visual tree assessment to identify potential hazards or the requirement for remedial tree work.
	•
	•

Notes

September 2016

BS 5837:2012 - Tree Protection Plan This drawing is to accompany a written. Crown spreads have been colour coded in accordance with the Standard. Root protection areas have been hatched RED for easier interpretation. Recommended tree protection has been displayed. Please refer to report for method statements. For further information relating to this survey please contact the surveyor: Ben Breaker - 07624 259720 - [email protected] {{image:768989}}

PROJECT

Ballabeg, Glen Vine

DRAWING NAME

Tree Protection

DWG by

BB

DATE

26/09/16

SCALE

1:000 @ A3

DWG No.

TP-25918v3

Notes:

Manx Roots Ltd. Eskdale, Bowring Road, Ramsey, Isle of Man, IM8 3EN T: 07624259720 | E: [email protected] | W: https://trees.im
