Jurby Totems Planning Document

Jurby Initiative

Planning document: Jurby Totems

Phase 1

July 2020

ABG Design

2048920

Jurby Initiative

A technical design drawing showing plan and elevation views of Corten steel totem structures with dimensions and a small reference photograph.

Phase 1

Jurby totem - scale view

100mm square
Notes:
Size: 300x2500mm
Material: Corten steel

Plan view

Line indicating base footprint
Front-on view
300mm
12 ABS 2020
CORPORATION

Notes:

Totem to sit
1750mm below ground level
Totem to sit
1750mm below ground level

Jurby Initiative

A photograph showing four tall, rusted metal feature totems standing on a concrete plinth with a stone building in the background.

Phase 1

Jurby totems - lighting specifications

The Pulse ChronoStrip X1 is a high performance linear LED future delivering outstanding results with a minimal power consumption.

Each ChronoStrip X1 unit can be built to meet your specification with numerous customisation options including project-specific 16L paint finishes, customised mounting brackets, and a complete range of beam angles in addition to single colour, 5xColour, and Variable White LED options.

KEY TECHNICAL DATA
12 L
55W
24V
66 ZONE
4 YEAR
100% Comfort
100% Comfort
100% Comfort
100% Comfort
100% Comfort
100% Comfort

*Drawing solely highlights the lighting location

Contact

ABG Design Howard Miles hmiles@abgdesign

01872248355
