An annotated photograph of a two-storey terraced building facade displaying digital measurement overlays for windows and doors.
Figure 2
An annotated photograph showing the rear elevation of a stone building with digital callouts indicating window dimensions and roof slope.
Figure 3
PLANNING & BUILDING CONTROL 2000 AND AGRICULTURE
Photograph of a rear ground floor facade featuring a central door and two sash windows, annotated with dimensional measurements.
Figure 12 Drawings showing the proposed location of the new boiler flue, which would be below the ridge and so not visible from the front
The image displays a floor plan of a residential property, detailing room layouts and dimensions for the ground and first floors.Architectural elevations showing front and side views of a building with dimensions and planning stamps.
Figure 4
A scanned document page displaying a design sketch of a proposed wooden front door with vertical paneling and a central rectangular window.
Figure 5
A scanned document page showing a detail of a proposed wooden rear door with a grid of windows and paneling, accompanied by a planning receipt stamp.
Figure 6
An annotated photograph showing a row of terraced houses, highlighting proposals for roof slate replacement and window upgrades.
Figure 7
REHAU Heritage sliding windows offer a number of features and benefits including:
Noise reduction
The double-glazed sealed units considerably reduce outdoor noise levels, allowing you to relax in the peace and quiet of your home.
Energy efficiency
The REHAU Heritage system can achieve an A rating, the highest possible Window Energy Rating (WER), therefore reducing heat loss and keeping out draughts.
REHAU windows and doors will comply with Part L Building Regulations providing the correct glazing unit is used. For windows this requirement is an overall U -Value of $1.6 \mathrm{~W} / \mathrm{m}^{2} \mathrm{~K}$ and for doors $1.8 \mathrm{~W} / \mathrm{m}^{2} \mathrm{~K}$.
Safety and security
The superb period look is backed up by a very modern approach to security. Our three-chamber sash profiles allow for even stronger reinforcements.
Low maintenance
Our systems contain a unique compound with a smooth gloss finish - guaranteeing they retain their pristine appearance. It also means they will never warp, rot or need regular painting.
Superbly engineered and of exceptional quality, REHAU Heritage windows will add real style to your home, guaranteeing maximum efficiency and performance for your investment.
Figure 8
A close-up photograph of a wooden window frame, appearing to be a traditional sash style, isolated against a plain background.Annotated photograph showing the rear roof slopes and chimney of adjacent properties, highlighting a proposed boiler flue location.
Figure 9
Vertical flue options
$L=$ Flue length, measured from the top of the boiler to the underside of the roof flashing Maximum flue length is 10 m plus external vertical roof terminal. The maximum flue length must not be exceeded (refer to $L$ in table below). For each additional $90^{\circ}$ or $2 \times 45^{\circ}$ bends fitted, the maximum flue length must be reduced by 1 m . The pipe length is reduced by 500 mm for each $45^{\circ}$ elbow and 1 m for each $87^{\circ}$ elbow used. Vertical flue options use the same 100 mm diameter flue components as the horizontal flue options. The vertical flue adaptor $G$ is required for vertical installations.
A close-up photograph showing a black boiler flue pipe protruding from a slate roof next to a stone gable wall, accompanied by an annotation explaining the flue's position relative to a neighboring property.A technical detail drawing showing a boiler flue pipe penetrating a sloped roof structure with dimensional annotations in millimeters.The image displays a technical specification sheet for a boiler flue system, featuring a diagram of the flue assembly on the left and a table listing model numbers, extension lengths, and part descriptions on the right.
